Belt-driven linear stage are automated mechanical devices that utilise a belt transmission system to achieve reciprocating linear motion of a slider. They find extensive application within industrial automation. Primarily comprising a drive unit, transmission mechanism, slider, and guide rails, these systems feature a simple structure, smooth operation, and high precision. Its operating principle is relatively straightforward: an electric motor drives the drive pulley of a synchronous toothed belt, which in turn propels the belt along linear guides. This action moves the slide block along a predetermined trajectory. By adjusting the motor's rotational speed and direction, precise control over the slide block's velocity and movement direction can be achieved.
Key advantages:
Belt-driven stage offer the following significant advantages over other transmission methods:
1. High operating speed: Maximum speeds of 2–5 m/s, substantially exceeding those of ball screw drives
2. Extended stroke: Maximum strokes exceeding 5 metres, suitable for long-distance conveyance
3. Low noise: Synchronous belt transmission produces minimal noise and operates smoothly
4. Cost-effectiveness: Simple construction results in relatively low manufacturing costs
5. Easy maintenance: Belt systems require straightforward upkeep and facilitate convenient reply
FAQ
1.Q: Can you manufacture customized products?
A: Yes, as long as you provide us with samples or design drawings, we can manufacture the product you want.
2.Q:If can offer sample before order?
A:Yes, we can offer free sample for quality test.
3.Q: How long has your company been in this field?
A: We have been focusing on automation machinery parts for ten years, and our products are sold all over the world, such as Europe, America, Asia, Southeast Asia, Africa and other places.
4.Q: What are your main products?
A: Our main products are linear shafts, linear bearings, ball screws, TBR linear guides, SBR linear guides, linear slide blocks and rod end bearings.
5.Q: What are your after-sales standards?
A: After our product is shipped, if there are any problems,please contact our sales personnel as soon as possible and we will handle them for you as soon as possible.
6.Q:What are your packaging conditions?
A: Generally speaking, our goods are packaged in neutral boxes and wooden boxes.
